01 Introduction

The Olimem Customer Portal API provides a secure integration framework allowing mobile applications, web applications, payment gateways, chatbots, and third-party systems to interact with the municipal billing and receipting platform.

The API supports

Customer Authentication
Account Balance Enquiries
Statements
Notifications
Service Requests
Meter Reading Submissions
Outage Management
Document Distribution
Payment Status Verification
Transaction Posting
Mobile POS Synchronisation

02 Authentication

2.1 Customer Authentication

Login authenticates as the calling council's customer-facing application first, then as the customer — every other Customer API request after that uses a Laravel Sanctum bearer token. Customer API is always council-scoped (no global-key support — see §4 Bot API for the channels that do span multiple clients).

POST /api/customer/login

Request headers

Content-Type: application/json
Accept: application/json
X-API-KEY: YOUR_COUNCIL_CUSTOMER_KEY
X-API-SECRET: YOUR_COUNCIL_CUSTOMER_SECRET

Request payload

{
  "account_number": "12345",
  "password": "Password@123"
}

X-API-KEY / X-API-SECRET identify which council's customer-facing application is calling (channel customer_portal, one key per council — issued from the hub's API Clients page) — not the customer. They scope the account_number lookup to one council so the same account number in two different councils can never collide. account_number / password then identify the specific customer within that council. The bearer token returned below is per-customer and is what every other Customer API request uses — it's safe to store in the browser precisely because it only ever represents one resident, not the whole council.

Successful response

{
  "success": true,
  "token": "1|fdfgdfgdfgdfgdfgdfg",
  "user": {
    "id": 1,
    "name": "John Doe",
    "fname": "John",
    "lname": "Doe",
    "email": "john@example.com",
    "phone": "0771234567",
    "account_no": "12345"
  },
  "account": {
    "name": "John Doe",
    "account": "12345",
    "currency": "USD",
    "balance": "123.45",
    "address": "123 Main Street"
  }
}

Failed response

{
  "success": false,
  "message": "Invalid account number or password."
}

Authorization header (all subsequent Customer API requests)

Authorization: Bearer {TOKEN}

03 Customer API

All endpoints below require the Authorization: Bearer {TOKEN} header obtained from Customer login. Formerly Portal API — renamed, same behavior.

3.1 Logout

POST/api/customer/logout

Response

{
  "success": true,
  "message": "Logged out."
}

3.2 Get Customer Profile

GET/api/customer/profile

Response

{
  "success": true,
  "user": {
    "id": 1,
    "name": "John Doe",
    "fname": "John",
    "lname": "Doe",
    "email": "john@example.com",
    "phone": "0771234567",
    "account_no": "12345"
  },
  "account": {
    "name": "John Doe",
    "account": "12345",
    "currency": "USD",
    "balance": "123.45",
    "address": "Bulawayo"
  }
}

3.3 Update Profile

PUT/api/customer/profile

Request payload

{
  "fname": "Kelvin",
  "lname": "Mtetwa",
  "phone": "0771234567",
  "current_password": "OldPassword",
  "new_password": "NewPassword123",
  "new_password_confirmation": "NewPassword123"
}

Response

{
  "success": true,
  "message": "Profile updated."
}

Password fields are optional on this endpoint — only send them when the customer is actually changing their password.

3.4 Account Balance

GET/api/customer/balance

Response

{
  "success": true,
  "account": "12345",
  "name": "John Doe",
  "currency": "USD",
  "balance": "123.45"
}

3.5 Customer Statement

GET/api/customer/statement

Response

{
  "success": true,
  "account": "12345",
  "currency": "USD",
  "balance": "123.45",
  "receipts": [
    {
      "id": 1,
      "reference": "REC-0001",
      "amount": "50.00",
      "date": "28 Jul 2026",
      "source": "Customer"
    }
  ]
}

3.6 Notifications

GET/api/customer/notifications

Response

{
  "success": true,
  "unread_count": 3,
  "notifications": [
    {
      "id": 1,
      "type": "info",
      "title": "Water Outage",
      "message": "Scheduled maintenance.",
      "is_read": false,
      "created_at": "2026-07-28 10:00"
    }
  ]
}

POST/api/customer/notifications/{id}/read

Response

{
  "success": true
}

3.7 Service Requests

POST/api/customer/service-requests

Request payload

{
  "category": "water_leak",
  "title": "Burst Pipe",
  "description": "Water leaking outside property.",
  "property_id": 145
}

Response

{
  "success": true,
  "reference": "SR-ABCD1234",
  "message": "Service request submitted."
}

Available categories

water_leak
sewer_burst
refuse_not_collected
streetlight_fault
billing_query
meter_fault
road_damage
other

3.8 Meter Readings

POST/api/customer/meter-readings

Request payload

{
  "property_id": 145,
  "service_id": 5,
  "reading_date": "2026-07-28",
  "reading_value": 2530,
  "meter_number": "MTR-001",
  "notes": "Customer reading."
}

Response

{
  "success": true,
  "id": 10,
  "message": "Meter reading submitted successfully."
}

GET/api/customer/meter-readings

Response

{
  "success": true,
  "readings": [
    {
      "id": 1,
      "reading_date": "28 Jul 2026",
      "reading_value": 2500,
      "previous_reading": 2450,
      "consumption": 50,
      "meter_number": "MTR-001",
      "status": "pending"
    }
  ]
}

3.9 Outages

GET/api/customer/outages

Response

{
  "success": true,
  "outages": [
    {
      "id": 1,
      "title": "Water Outage",
      "description": "Pipe maintenance",
      "type": "water",
      "area": "CBD",
      "severity": "high",
      "status": "scheduled"
    }
  ]
}

3.10 Documents

GET/api/customer/documents

Response

{
  "success": true,
  "documents": [
    {
      "id": 1,
      "title": "July Invoice",
      "category": "Invoice",
      "file_name": "invoice.pdf",
      "file_type": "pdf",
      "file_size": "1.2 MB",
      "url": "https://yourdomain.com/storage/invoice.pdf"
    }
  ]
}

04 Bot API

Used by the per-council WhatsApp bot only. Authenticated with an API key/secret pair instead of a bearer token — a per-council key (channel whatsapp), never a bank's global key. Banks have their own separate §4c Bank API, with its own routes and its own credential shape — not shared with this one.

Authentication headers (all Bot API requests)

X-API-KEY: YOUR_API_KEY
X-API-SECRET: YOUR_API_SECRET

Bot Login

POST/api/bot/login

Request payload

{
  "account_number": "12345",
  "password": "Password@123"
}

Response

{
  "success": true,
  "name": "John Doe",
  "account": "12345",
  "currency": "USD",
  "balance": "123.45"
}

Account Lookup

GET/api/bot/account/{account}

Response

{
  "success": true,
  "dc_link": 123,
  "account": "12345",
  "name": "John Doe",
  "currency": "USD",
  "balance": "123.45"
}

GET/api/bot/balance/{account}

Balance Lookup — same response shape as Account Lookup.

GET/api/bot/statement/{account}

Statement Lookup — same response shape as Customer Statement.

Service Request

POST/api/bot/service-request

Request payload

{
  "account": "12345",
  "category": "water_leak",
  "title": "Burst Pipe",
  "description": "Pipe burst outside property."
}

04b Accounts API

Lists every client (account) in the calling council — account number, name, phone, address, balance. Usable by any front-door key (Banks, WhatsApp, Customer Portal) for the council it belongs to.

Authentication headers

X-API-KEY: YOUR_API_KEY
X-API-SECRET: YOUR_API_SECRET

GET/api/accounts

Query parameters

per_page (optional, default 50, max 200)

Response

{
  "success": true,
  "council": { "code": "RIVERVIEW_TC", "name": "Riverview Town Council" },
  "clients": [
    {
      "account_number": "56114",
      "name": "Shanel Connelly",
      "phone": "0728723933",
      "address": "8953 Herbert Court",
      "currency": "USD",
      "balance": "113.88"
    }
  ],
  "meta": { "current_page": 1, "per_page": 50, "total": 202, "last_page": 5 }
}

Scoped to the calling council from the API key — there is no way to request another council's clients through this endpoint.

04c Bank API

Its own fully separate channel — own routes, own controllers, not shared with Bot API. Banks have full access to any council through a global key (no single council on the credential itself, unlike every other channel) — every other endpoint on the hub rejects a global key outright. A per-council bank key (issued the normal way) still works on every route below too, exactly like any other channel's key.

Authentication headers

X-API-KEY: YOUR_GLOBAL_API_KEY
X-API-SECRET: YOUR_GLOBAL_API_SECRET

Bank-wide (global key only)

These three see every council at once — there's no council_code involved, and a per-council key gets 401 here.

GET/api/bank/councils

Response

{
  "success": true,
  "councils": [
    { "code": "CENTRAL_MUN", "name": "Central Municipality", "type": "Municipality" },
    { "code": "NORTHDALE_RDC", "name": "Northdale Rural District Council", "type": "RDC" },
    { "code": "RIVERVIEW_TC", "name": "Riverview Town Council", "type": "Town Council" },
    { "code": "EASTFIELD_RDC", "name": "Eastfield Rural District Council", "type": "RDC" }
  ]
}

The reference list of every active council's code, name and type — useful before calling /api/bank/clients below.

GET/api/bank/transactions

Query parameters

council_code (optional — omit for every council)
status (optional: pending, posted, failed)
date (optional, single day)
from / to (optional, date range)
per_page (optional, default 50, max 200)

Response

{
  "success": true,
  "transactions": [
    {
      "council_code": "RIVERVIEW_TC",
      "council_name": "Riverview Town Council",
      "reference": "PAY-20260827-001",
      "zb_reference": null,
      "account_number": "10001",
      "customer_name": "John Doe",
      "amount": "5.00",
      "type": "payment",
      "source": "connector",
      "paid_by": "John Doe",
      "status": "posted",
      "sage_reference": "1249.001",
      "failure_reason": null,
      "created_at": "2026-08-27T10:05:44+00:00",
      "posted_at": "2026-08-27T10:06:01+00:00"
    }
  ],
  "meta": { "current_page": 1, "per_page": 50, "total": 4, "last_page": 1 }
}

The reconciliation feed — match this against your own settlement file instead of polling /api/zb/payment/{reference} one reference at a time.

GET/api/bank/clients

Query parameters

per_page (optional, default 50, max 200)

Response

{
  "success": true,
  "clients": [
    {
      "council_code": "EASTFIELD_RDC",
      "council_name": "Eastfield Rural District Council",
      "account_number": "39480",
      "name": "Jane Moyo",
      "phone": "0771234567",
      "email": "jane@example.com",
      "address": "12 Main Street",
      "currency": "USD",
      "balance": "45.20"
    }
  ],
  "meta": { "current_page": 1, "per_page": 50, "total": 2066, "last_page": 42 }
}

Every client, from every active council, in one response — each one tagged with council_code/council_name. Issue a global key via php artisan olimem:issue-global-key.

GET/api/bank/services

?council_code= (strongly recommended — some councils carry 1,000s of services) + optional ?type=Municipal|Normal. Omitting council_code sweeps every council in one paginated response.

GET/api/bank/tenders

?council_code= (same recommendation as bank/services above).

GET/api/bank/properties

?council_code= (same recommendation) — property id, owner name, address, erf number, for every council or one.

At real scale (60+ councils, some with 3,000+ services/properties) sweeping every council for a lookup is expensive — you're almost always about to post a payment for one specific council anyway, so always pass council_code here rather than relying on the no-filter fallback.

Single-account (global or per-council key)

Same shape as Bot API's equivalents (§4), on their own /api/bank/* routes. A global key must add council_code — a per-council bank key resolves it from the key itself and can omit it.

POST/api/bank/login

Request payload (global key)

{
  "council_code": "EASTFIELD_RDC",
  "account_number": "12345",
  "password": "Password@123"
}

Response

{
  "success": true,
  "name": "John Doe",
  "account": "12345",
  "currency": "USD",
  "balance": "123.45"
}

GET/api/bank/account/{account}

Query parameters

council_code (required for a global key only)

Response

{
  "success": true,
  "dc_link": 123,
  "account": "12345",
  "name": "John Doe",
  "currency": "USD",
  "balance": "123.45"
}

GET/api/bank/balance/{account}

Balance Lookup — same response shape as Account Lookup.

GET/api/bank/statement/{account}

Statement Lookup — same response shape as Bot API's Statement Lookup.

POST/api/bank/service-request

Request payload (global key)

{
  "council_code": "EASTFIELD_RDC",
  "account": "12345",
  "category": "billing_query",
  "title": "Disputed charge",
  "description": "Customer disputes the water bill amount."
}

04d Services API

Lists the calling council's service/product catalog, as synced up from Sage by the connector — StkItem for Normal-type sales, _ccg_EB_Services for Municipal-type billing. A council with no municipal billing module configured in Sage simply returns zero Municipal rows — not an error. Use the returned id as property_id+service_id (Municipal) or stock_id (Normal) on §6 Transact API.

Authentication headers

X-API-KEY: YOUR_API_KEY
X-API-SECRET: YOUR_API_SECRET

GET/api/services

Query parameters

type (optional: Municipal, Normal — omit for both)
per_page (optional, default 100, max 500)

Response

{
  "success": true,
  "council": { "code": "RIVERVIEW_TC", "name": "Riverview Town Council" },
  "services": [
    { "id": 1, "type": "Municipal", "name": "Water Consumption", "description": "Water Cons" },
    { "id": 42, "type": "Normal", "name": "Stationery Pack", "description": null }
  ],
  "meta": { "current_page": 1, "per_page": 100, "total": 2, "last_page": 1 }
}

Scoped to the calling council from the API key. Populated by the connector's read-direction sync — if a council was only just onboarded, this list fills in over the connector's first few cycles.

04e Tenders API

Lists the calling council's payment methods, as synced up from Sage's own dbo.Tender table by the connector (Cash, EcoCash, Card, bank transfer, etc.). Pass the returned id back as tender_id on §6 Transact API to choose how a payment posts — omit it and Municipal payments still fall back to the service's own tariff, unchanged.

Authentication headers

X-API-KEY: YOUR_API_KEY
X-API-SECRET: YOUR_API_SECRET

GET/api/tenders

Query parameters

per_page (optional, default 100, max 500)

Response

{
  "success": true,
  "council": { "code": "RIVERVIEW_TC", "name": "Riverview Town Council" },
  "tenders": [
    { "id": 6, "tender_no": "6", "name": "Cash USD" },
    { "id": 7, "tender_no": "7", "name": "ECOCASH (Merchant)-ZiG" }
  ],
  "meta": { "current_page": 1, "per_page": 100, "total": 2, "last_page": 1 }
}

Scoped to the calling council from the API key. A chosen tender only actually changes how a payment posts once the council's rcpt_service_tr_codes mapping is configured for that service+tender combination.

04f Properties API

Lists the calling council's property register, as synced up from Sage's own Properties by the connector — property id, owner name, address, erf number. Use the returned property_id together with a service_id from §4d Services API for a Municipal-type payment on §6 Transact API.

Authentication headers

X-API-KEY: YOUR_API_KEY
X-API-SECRET: YOUR_API_SECRET

GET/api/properties

Query parameters

per_page (optional, default 100, max 500)

Response

{
  "success": true,
  "council": { "code": "RIVERVIEW_TC", "name": "Riverview Town Council" },
  "properties": [
    { "property_id": 3, "owner_name": "John Doe", "address": "12 Main Street", "erf_number": "ERF-100" }
  ],
  "meta": { "current_page": 1, "per_page": 100, "total": 1, "last_page": 1 }
}

Scoped to the calling council from the API key. A council with no municipal billing module configured in Sage returns an empty list, same as Services API's Municipal type — not an error. owner_name is the client's current billing name (Sage Client.Name), not the deed-registered name, which can go stale.

05 Payment Gateway API

Payment Status

GET/api/zb/payment/{reference}

Query parameters

council_code (required for a global/bank key only — per-council keys resolve it from the key itself)

Response

{
  "success": true,
  "merchant_reference": "ZB-1234",
  "zb_reference": "ZB202607280001",
  "status": "paid",
  "is_paid": true,
  "amount": "50.00",
  "email": "customer@example.com",
  "phone": "0771234567",
  "receipt": {
    "id": 1,
    "reference": "REC-0001"
  }
}

06 Transact API

Allows external systems (payment gateways, third-party billers) to post transactions directly into Sage Evolution. type picks which of Sage's two billing shapes the payment belongs to — look the right ids up first via §4d Services API and §4e Tenders API.

POST/api/transact

Headers

X-API-KEY: YOUR_API_KEY
X-API-SECRET: YOUR_API_SECRET
Accept: application/json
Content-Type: application/json

account (required)
type (optional: Municipal, Normal — default Municipal)
property_id + service_id (required if type=Municipal — see Services API)
stock_id (required if type=Normal — see Services API)
tender_id (optional — see Tenders API)
amount (required)
currency (optional: ZWG, USD, ZAR — the currency the payer paid in; omit to use the account's own currency)
reference (required, unique)
description, paid_by (optional)

Municipal payment (per-council key)

{
  "account": "12345",
  "type": "Municipal",
  "property_id": 1001,
  "service_id": 1,
  "tender_id": 6,
  "amount": 100.00,
  "reference": "PAY-20260728-001",
  "description": "Online Payment",
  "paid_by": "John Doe"
}

Normal payment — a plain stock item, no property involved

{
  "account": "12345",
  "type": "Normal",
  "stock_id": 42,
  "tender_id": 7,
  "amount": 25.00,
  "reference": "PAY-20260728-002"
}

Global key (banks) — add council_code

{
  "council_code": "EASTFIELD_RDC",
  "account": "12345",
  "amount": 100.00,
  "reference": "PAY-20260728-001",
  "description": "Online Payment"
}

Success response

{
  "success": true,
  "receipt_id": 123,
  "reference": "REC-0001",
  "message": "Transaction posted successfully."
}

reference must be unique per transaction — retrying with the same reference must not post the payment twice. There is no currency field — a payment always posts in the account's own synced currency.

tender_id is optional and Municipal payments still work without it (falls back to the service's own tariff, unchanged from before). Normal payments have no fallback — without a resolvable tender/service TR-code mapping configured on the council's side, the payment is accepted but fails to post into Sage.

07 Sync API

Used by the Android receipting application to pull reference data and push offline receipts once connectivity returns.

Available endpoints

GET /api/sync/stk-items
GET /api/sync/clients
GET /api/sync/accounts
GET /api/sync/tenders
GET /api/sync/currencies
GET /api/sync/currency-hist
GET /api/sync/price-list-names
GET /api/sync/price-list-prices
GET /api/sync/tr-codes
GET /api/sync/properties
GET /api/sync/services
GET /api/sync/property-services
GET /api/sync/tender-configurations
GET /api/sync/service-trcodes

Offline Receipt Synchronisation

POST/api/sync/receipts-post

Full payload

{
  "clientLink": 1001,
  "customerCurrencyId": 1,
  "type": "Municipal",
  "userId": 1,
  "openBalance": 500.00,
  "paid_by": "John Doe",
  "posted": true,
  "createdAt": "2026-07-28 10:00:00",
  "reference": "ANDROID-0001",
  "source": "Android",
  "items": [
    {
      "is_cash": true,
      "createdAt": "2026-07-28 10:00:00",
      "type": "Municipal",
      "clientLink": 1001,
      "trcode": 1,
      "amount": 100.00,
      "tendered_amount": 100.00,
      "change": 0,
      "taxAcc": 1,
      "taxTypeID": 1,
      "description": "Water Charges",
      "stockId": 1,
      "iot": 0,
      "refundTrcode": 0,
      "isBillable": true,
      "currencyID": 1,
      "userId": 1
    }
  ]
}

Same idempotency rule as the Transact API — reference must be unique per receipt so a retried sync never double-posts.

Mobile Device Login

POST/api/sync/login

Request payload

{
  "email": "user@council.co.zw",
  "password": "Password@123",
  "deviceUUID": "123456789",
  "deviceName": "Samsung Tablet",
  "deviceModel": "SM-T500"
}

08 Miscellaneous Endpoints

GET/api/user

Current authenticated user (Sanctum session).

GET/api/test

Response

{
  "status": "working",
  "app": "Olimem Customer Portal"
}

09 Error Handling

Standard error response

{
  "success": false,
  "message": "Error Description"
}

Common status codes

Code	Description
200	Success
201	Created
400	Bad Request
401	Unauthorized
403	Forbidden
404	Not Found
422	Validation Error
500	Internal Server Error

10 Security Recommendations

Enforce HTTPS for all environments.
Rotate API keys periodically.
Store API secrets securely.
Implement IP whitelisting.
Enable request auditing.
Use JWT / Sanctum token expiration.
Encrypt sensitive data.
Rate limiting — done: 120 req/min per API key on every machine-client route, 60 req/min per customer on Customer API routes (keyed by identity, not IP, so councils sharing this server never throttle each other).
Enable API monitoring.

11 Integration Flow

Customer App → Customer API → Laravel Application → Sage Evolution Database

Payment Gateway → Payment API → Receipting Engine → Sage Evolution

Android POS → Sync API → Sage Evolution → Fiscalisation Service

Chatbot → Bot API → Customer Portal → Sage Evolution

12 Appendix

Supported currencies

Supported authentication methods

Bearer Token
API Key
API Secret

Supported content types

application/json

Everything connected. Every transaction recorded.

Channels → hub → Sage Database

Trusted by organisations across Zimbabwe

Built for public money, across authorities

Identity from the key, never the request

Connectors dial out, the hub never dials in

Idempotent, always

Real payments, real councils

API Reference for integrators

01 Introduction

02 Authentication

2.1 Customer Authentication

03 Customer API

3.1 Logout

3.2 Get Customer Profile

3.3 Update Profile

3.4 Account Balance

3.5 Customer Statement

3.6 Notifications

3.7 Service Requests

3.8 Meter Readings

3.9 Outages

3.10 Documents

04 Bot API

Bot Login

Account Lookup

Service Request

04b Accounts API

04c Bank API

Bank-wide (global key only)

Single-account (global or per-council key)

04d Services API

04e Tenders API

04f Properties API

05 Payment Gateway API

Payment Status

06 Transact API

07 Sync API

Offline Receipt Synchronisation

Mobile Device Login

08 Miscellaneous Endpoints

09 Error Handling

10 Security Recommendations

11 Integration Flow

12 Appendix
